Description:
SLZ230 is suitable to serve for water pump factory, forming power unit with engine. It is widely used in industrial or civil water supply and drainage, central heating, boiler feed water, transportation of chemical fluid and slurry, oil transportation and water injection in oil field.
Main data:
Model： | SLZ230 pump gearbox |
Rated Power： | P=90KW |
Input Speed： | 1200-2200r/min |
Speed Increasing Ratio： | 2.39 |
Center distance： | 206mm |
Weight： | 220kg |
Input shaft steering：： | Counterclockwise (looking at the flywheel towards the output) |
Specification：： | Cylindrical helical gear two-shaft two- gear drive; Hydraulic wet multi-disc fiction clutch,manual valve, oil pressure automatic delay ascending device. |
Application:
SLZ230 is widely used in industrial or civil water supply and drainage, central heating, boiler feed water, transportation of chemical fluid and slurry, oil transportation and water injection in oil field.
